CSY-3200 Weighing type automatic quantitative liquid filling machine AC100-220V 30W Filling 3.2L / min

Product parameters

Product model: CSY-3200

Rated voltage: AC100-220V

Rated power: 30W

Product size: length 18cm* width 18cm* height 12cm

Machine weight: 2.5kg

Filling flow: ≤3.2L/min

Filling range: 10g～3kg

Maximum suction lift: 2 meters

Filling height: 0-35cm

Product Support:

Adjustable flow

data storage

Power-off memory

Automatic peeling

Automatic start and stop

Automatic frequency conversion

automatic count

Automatic reset

adjustable delay

This machine can be applied to: beverages/white wine/vinegar/soy sauce/juice and other products, essential oils, perfumes, liquid products, etc.

If you are not sure whether the product meets your requirements, please contact customer service to communicate

[Applicable requirements for weighing and quantitative filling machine]:

① The container to be filled must be a bottle that can stand upright. The liquid that can be filled must be: pure liquid, free of impurities and non-viscous.

② Cream, honey, diesel oil, engine oil, kerosene, gasoline are not suitable.

③The filling volume can be set: 5g-3kg, the division value is 1g. [For water: 1g (g) = 1mL (ml)]

Calibration scale:（During transportation, machine vibration may cause inaccurate weighing. Calibrate the scale in the following way）

① Restart the machine.
② Press the "Reset" key.
Press and hold the 【.】 key for three seconds. When you hear a beep, release your hand.
③ Place an object of known weight on the scale (for example: a 1000g weight).
④ Press the number keys to enter the weight of the object (for example: enter 1 0 0 0).
⑤ Finally, press and hold the 【.】 key for three seconds. When you hear a beep, release your hand. The calibration is complete.

CSY-3200 Weighing Automatic Quantitative Liquid Filling Machine, Red wine, soy sauce, potion, cosmetic lotion liquid filling
