KONALET H61 Motherboard LGA1155 DDR3 Support Intel i3 i5 i7 2nd 3rd Gen USB2.0 SATA2 VGA HDMI Micro ATX Desktop Mainboard

Product Description

1. Wide CPU Compatibility
Supports Intel LGA1155 socket, compatible with Core i3 / i5 / i7 2nd & 3rd generation processors, stable and versatile for different PC builds.

2. Stable DDR3 Performance
Supports DDR3 memory for smooth multitasking, ideal for office work, home use, and entry-level systems.

3. Multiple Display Outputs
Equipped with VGA / HDMI ports, supports dual display setup, improving work efficiency and user experience.

4. Reliable & Durable Design
Built with stable components and strict quality control, ensuring long-term performance and low failure rate.

5. Cost-Effective Solution
Perfect choice for bulk purchase, system integrators, and budget PC builds with excellent price-performance ratio.

Product Specifications

CPU：Supports LGA1155 Socket I3/I5/I7 series CPU

Chipset：Intel H61 Express Chipset

Memory：2*240-pin DDRⅢ SDRAM slots
Memory up to 16GB
Supports dual channal DDR3
1066/1333/1600 MHZ

I/O interface：
6xUSB2.0
1x VGA port
1x HDMI port
1x RJ45 port
1x 3-in-1 Audio port(line in/line out/MIC in)
Onboard interface 1x 24-pin ATX power
connector
1x 4-pin ATX 12V power connector
2x USB connector, can support 4*USB 2.0
1x F-AUDIO connector
1x F-PANEL connector
1x F-SPEAKER connector
1x FAN connector
1x TMP/LPC-DEBUG connector
connector(ASUS LPC protocol)
Integrated sound：Realtek ALC 6-channal
HD Audio Codec onboard
provides front audio interface
provides front stereo mic interface

Storage：3x SATA 2.0 (3GB/s) ports
Integrated lan：Realtek 100/1000 Mbps
LAN onboard (1000Mbps optional)

Expansion slot：1x PCI Express x16 slot
1x PCI Express x1 slot
1x M.2 Nvme/NGFF slot

Dimension：Micro-ATX architecture(17*19cm)
