LASER TREE 5W Laser Module with Air Assist 10W High Power TTL Blue Light Laser Head for DIY CNC Laser Engraving Cutting Machine

40W Laser Module with Air Assist for Laser Engraver Cutter

By LASER TREE

Product Features:

1.Beam compression technology, 5W optical power laser module.

2.Excellent Cutting Ability: Cutting 4mm plywood by one pass at a Speed of 190mm/s.

3.Very Fast Engraving Speed: 45mm focal length, engrave 304 stainless steel at speeds up to 6000mm/min.

4.Magnetic eye protective cover: Eye protection and easy disassembly.

5.For various 12V 3PIN laser engraving machines, plug and play. For 12V 4PIN machines, just use the driver adapter to connect.

Specification:

Effect output power: 40W

Output optical power: 5W

Material: aluminum alloy + plastic

Light color: blue

Wavelength: 450nm

Spot form: Punctiform, fixed focus

Input voltage: 12V 1.8A(1.5A-2A)

Interface: XH2.54-3PIN socket

Modulation: 0/5-12V 0-5kHz TTL/PWM

Item size: 40*40*141.4mm

Product weight: 255g

80W Laser Module with Air Assist for Laser Engraver Cutter

By LASER TREE

Features:

1. Powerful Air Assist Nozzle

The laser head is equipped with a specially designed air-assisted nozzle.Pro has an upgraded nozzle compared to the previous AA. The difference of this nozzle is that it has an advanced hydrodynamic design that makes better use of air pressure. When using the same air compressor, the upgraded version has a faster jet airflow.
Recommended inner diameter of air tube: Φ4mm,outer diameter: 8x6mm
Air pump suggestion:Air pressure and capacity: ≥0.027kPa, 27L/min

NOTE: To take full advantage of the air assist feature, it is recommended that you use it together with the air pump.

2. Magnetic Protective Cover
Equipped with a removable magnetic protective cover. Whether it is engraving or cutting, you can use this protective cover to filter blue light without laser goggles, safe and convenient.

3. High Power Laser Module--- 2-Beam compression technology, 10W optical power laser module

4. Powerful Cutting Ability
Cut 8mm bass plywood: 120mm/min,100% power,by one pass
Cut 5mm black acrylic: 50mm/min,100% power,by one pass
Cut 5mm MDF: 150mm/min,100% power,by 2 passes

5. Professional Air Assist--- Blowing through the air nozzle to get clean-cut edges, improve cutting performance

6. Super Fast Engraving Speed--- Ultra-fast engraving on stainless steel-30mm/s

7. Widely Compatibility--- Suitable for Z*aitu,O*tur,Tw* Trees,S*ulpful9, Xtool, A*omstack and other models of DIY laser engraving machines.

Specification:

Material: aluminum alloy

Effect output power: 80W

Optical Power：10W (±1W)

Wavelength: 450nm (±10nm)

Light color: blue

Focus Length: 45mm

Spot form: Punctiform, fixed focus

Electric power: 12V 3.2A(3A-3.5A); 24V 1.7A(1.5A-2A)

PWM Modulation: 0/3-12V 0-5kHz TTL/PWM

Input port: XH2.54-3P socket

Item size: 40*40*147mm

Laser module net weight: 250g

To make full use of the air assist, it is recommended to buy together with the air pump.

Air Pump:

Description

The air pump is an essential part of the laser module with air assisted.
It provides a steady high-pressure airflow to blow away smoke and obtain clean-cut edges;
Protecting the laser head's lens from contamination and extending the laser head's service life.
In addition, it can improve the efficiency of laser processing and thus save your time.

Features：

1. High-quality Materials: metal nozzle, resisting high temperature.

2. Large and Steady Air Output: Adjustable airflow of 0-27L/min, blowing away smoke and residue produced during laser processing, cut deeper、faster and cleaner.

3. Low Noise & Low Vibration: Anti-slip& damping feet keep the body stable and reduce the vibration noise effectively.

4. Rapid Heat Dissipation: Aluminum alloy shell, strong heat dissipation, long lasting and more durable.

5. Plug and Play: please select the correct version of EU/US/AU plug.

Specification:

Air output: ≥26L/min
Voltage：DC24V
Current: 950mA
Pressure: ≥28kPa
Environmental temperature: -20℃-40℃
Environmental humidity: <90%
